14
www.level1.com
POM-1100
PoE Module
- Works well with LevelOne
BOH-1100/1200/1300
- 12V DC/2.5A High-Power PoE
Splitter Module
- Power for IP Cam, IR LEDs,
housing heater and fan all
from a single PoE cable
- Supports High-Power up to
30W
- For PoE and non-PoE Cameras
- All necessary accessories
included
- Easy installation
FCS-5011
Day/Night Outdoor PoE Network
Camera
- 1/3.3" Progressive CMOS,
720 x 480
- MPEG4 and MJPEG compression
- Dual streams simultaneously
- Removable IR-cut flter for day
and night viewing
- WDR (Wide Dynamic Range)
helps handling a wide range of
lighting conditions in a scene,
such as backlight situation
- 3.3~12mm vari-focal board lens
with auto-iris for a variety of
monitoring felds
- IP66 weatherpoof outdoor
housing
- RS-485 interface for scanner or
pan/tilt control
- Digital Input/Output (1 DI/1 DO)
for sensor/alarm
- Built-in infrared LEDs for night
viewing up to 15m
- 802.3af PoE compliant for easy
network deployment
- Max. power consumption: 6.5W
How does an indoor camera become an outdoor camera?
LevelOne provides strong and durable outdoor housings (BOH-1100/BOH-1200/BOH-1300) for the
camera models FCS-1091/FCS-1101/FCS-1121/FCS-1131/FCS-1141/FCS-1151 – Flexible and easy
to turn an indoor camera into an outdoor camera (refer to page 26).
FCS-5041
Day/Night Megapixel PoE
Outdoor Network Camera
- 1/4” Progressive CMOS
Megapixel, 1280x800
- H.264, MPEG4 and MJPEG
compression
- Dual streams simultaneously
- Remote access with Level1DNS™
service
- Removable IR-cut flter for Day/
Night viewing
- Provides an external USB
interface for an optional outdoor
wireless solution or USB fash
drive
- Built-in Infrared LEDs for night
viewing up to 15m
- Smart Focus to get excellent
image quality
- IP67 waterproof outdoor housing
with built-in fan and heater
- Triple power support:
12V DC/24V AC/PoE (802.3af )
- Max. Power Consumption: 12W
FCS-5051
Day/Night 2-Megapixel PoE
Outdoor Network Camera
- 1/2.7” Progressive CMOS
2-Megapixel, 1920x1080
- H.264 and MJPEG compression
- Dual streams simultaneously
- Removable IR-cut flter for Day/
Night viewing
- Built-in Infrared LEDs for night
viewing up to 20m
- IP66 weatherpoof outdoor
housing
- Supports 2 privacy masks for
private area protection
- Supports up to 20 viewers
simultaneously
- Sun shield and cable
management bracket for
protected installation
- Built-in micro SD/SDHC memory
card slot for local storage
- Triple power support:
12V DC/24V AC/PoE (802.3af )
- Max. Power Consumption: 12W
iPhone
iPhone
iPhone
FCS-1101
PoE Network Camera
- 1/3" CCD, 704 x 480
- MPEG4 and MJPEG compression
- Dual streams simultaneously
- Features 10x digital zoom
- Up to 30 fps in full D1 resolution
- Features motion detection and
event notifcation via E-mail
- UPnP for fast and easy
installation
- 802.3af PoE compliant for easy
network deployment
- Max. power consumption: 6W
- Optional outdoor housing:
BOH-1100/BOH-1300
*Power adapter not included
