61
KVM Switches/Consoles/Extenders
BUSINESS
LevelOne KVM Switches/Consoles/Extenders
LevelOne KVM switches include award-winning designs that look great on any desktop. With a small footprint and plug-and-
play installation, these devices help you to switch between computers with ease. Both PS/2 and USB connections are available
to support any operating system. Our professional level rackmount and drawer consoles provide advanced features such as
remote management and control of up to 128 diferent servers.
KVM-0421 / KVM-0422
4-Port USB KVM Switch
- Control and manage 4 computers by using a single
USB keyboard, mouse and monitor
- High 2048x1536 pixels VGA resolution
- USB interface power supply
- Easy switching between computers with keyboard
hotkeys push button and utility (or software) selection
- Plug-and-play operation, no software installation or
power supply required
- At-a-glance LED for easy monitoring of PC activity
- Audio support allows user to connect the audio ports
of each computer to the KVM switch (KVM-0421)
KVM-0411 / KVM-0412
4-Port PS/2 KVM Switch
- Flexible switching for uninterrupted multimedia
- Control and manage 4 computers by using a single
PS/2 keyboard mouse and monitor
- Ofers user-programmable simultaneous or
independent PC and audio switching
- High 2048x1536 pixels VGA resolution
- Auto-scan mode for PCs monitoring
- LED display for easy monitoring of PC activity
- Plug-and-play operation, no software installation or
power supply required
- Audio support allows user to connect the audio ports
of each computer to the KVM switch (KVM-0411)
KVM-0306
3-Port DVI KVM Switch with Audio
- Features a DVI interface for better video quality
through digital signal transmission
- Controls 3 DVI computers from a single console
through USB and/or PS/2 connections
- Self-powered through USB connection
- Connecting cable sets are include
- Audio enabled for multimedia applications
- DVI UXGA resolution of 1600x1200 @ 60Hz
- Supports hot-swapping
Desktop KVM Switches
KVM-0411
KVM-0412
KVM-0421
KVM-0422
KVM Switches Comparison
Model
Ports Console Interface Computer Interface Platform Support Max. Local Resolution Audio
KVM-0411
4
PS/2, D-Sub
PS/2, D-Sub
PC
2048x1536
n
KVM-0412
4
PS/2, D-Sub
PS/2, D-Sub
PC
2048x1536
-
KVM-0421
4
USB, D-Sub
USB, D-Sub
PC, Mac, Sun
2048X1536
n
KVM-0422
4
USB, D-Sub
USB, D-Sub
PC, Mac, Sun
2048X1536
-
KVM-0306
3
PS/2, USB, DVI
USB, DVI
PC, Mac, Sun
1600X1200
n
UP to 8
Console
KVM Switch
KVM Consoles
Works With
KVM consoles Module
Windows Server
Netware
Unix
Linux
Mac OS
Sun Microsystem
Remote
Console
Router
Internet
KVM Station
Ethernet
KVM Console Receiver
Cat.5 Up to 300m
